NO.149 STRESS-CRACKING TESTER



NO.149 STRESS-CRACKING TESTER



  • Standard Method : JIS-K6922-2, Z1703, ASTM-D1693, ISO-1872-2

  • This tester is used to test the constant strain environmental stress cracking of plastic.

  • The testing method is to fix the notched test specimen to the test specimen holding jig and dipping it into a test tube that is filled with test liquid adjusted at 50°C.

  • The operator is to observe the time it required for the stress crack to arise.

  • Click Here : No.149 Stress-Cracking Catalog

  • Click Here : Plastic, Rubber, Film and Polymer Product Catalog

Specification Yasuda Seiki

No.149 Stress-Cracking Tester

Specimen

W13 ± 0.8 mm,

L38 ± 2.5 mm,

T3 mm or 2 mm

Notching

Jig

Notch Depth 0.5 mm, 0.3 mm,

Notch Length 19.1 ± 0.1 mm

Bending Jig

1 set

Transfer Jig

1 set

Accessories

Test Tube (Outer φ30 × 200 mm),

Cork Cap, Aluminum Foil,

Specimen Fixing Jig: 5 sets each

Dimensions /

Weight(Approx)

W320 × D50 × H65 mm /

2.5 kg (Notching Jig)



PT. Mora Anugerah Berkat adalah perusahaan yang sudah berpengalaman dalam menyediakan/mensupply peralatan laboratorium untuk plastic,film,rubber dan polymer testing, salah satu diantaranya adalah No.149 Stress-Cracking Tester, kami juga menyediakan peralatan yang terbaik,sudah teruji dan sesuai dengan standard  ASTM/JIS dll,kami juga menyediakan berbagai brand/merk internasional dari USA,Eropa dan China,

NO.149 STRESS-CRACKING TESTER



Kami juga menyediakan Jasa Perbaikan (SERVICE),Jasa Perawatan (Maintenace) dan support untuk KALIBRASI/AKSESSORIES SPAREPART jangan ragu untuk menghubungi kami marketing dan sales kami siap membantu menjawab segala kebutuhan anda
