Supplier Oven Lab - Forced Air Drying Oven di LTC Glodok
Supplier Oven Lab - Forced Air Drying Oven di LTC Glodok
PT. Mora Anugerah Berkat (M.A.B) adalah perusahaan yang bergerak dalam bidang laboratorium khususnya general laboratory equipment seperti Oven, Drying Oven, Hotplate, Hot Plate Stirrer, pipette dan lain - lain , jika anda membutuhkan / mencari alat laboratorium diantaranya forced drying oven jangan ragu untuk menghubungi atau bertanya tentang forced drying oven specification atau model/type forced drying oven seperti yang ada di bawah ini :
DOF-50B Forced Air Drying Oven
-
External material: cold-rolled steel with anti-bacteria powder coating.
-
Stainless steel inner chamber, round angle structure, adjustable shelves.
-
Double-layer glass observation window, adjustable airtight buckle lock.
-
PID control with LED display.
-
Over-temperature protection.
Specification
|
DOF-50B Forced Air Drying Oven
|
Model
|
DOF-50B
|
Capacity
|
50L
|
Temp. Range
|
RT+5~250℃
|
Temp. Precision
|
0.1℃
|
Temp. Fluctuation
|
±1℃
|
Ambient Temp.
|
5~40℃
|
Timing Range
|
1~9999min
|
Heat up time
|
Min 11 Min
|
Shelves No.
|
2 pcs for standard
|
Power Consumption
|
1000W
|
Power Supply
|
Standard : 220V ± 10 %, 50/60 Hz ; Optional : 110V, 60 Hz
|
Internal Size (W x D x H) mm
|
400 x 300 x 400
|
External Size (W x D x H) mm
|
650 x 450 x 600
|
Package Size (W x D x H) mm
|
840 x 690 x 700
|
Gross Weight (kg)
|
60
|
Supplier Oven Lab - Forced Air Drying Oven di LTC Glodok
Drying Oven Product Catalog
|
FAITHFUL Drying Oven
|
BIOBASE Drying Oven
|
|
|
|
SUS304 Forced Air Drying Oven Characteristics : WGLL-BE series have the folloeing characteristics other than the above functions.
-
LCD temperature controller.
-
Over-temperature protection system.
-
High precision digital independent temperature limiter.
Model
|
WGLL-30BE (SUS304)
|
WGLL-45BE (SUS304)
|
WGLL-65BE (SUS304)
|
WGLL-85BE (SUS304)
|
WGLL-125BE (SUS304)
|
WGLL-230BE (SUS304)
|
Cycle Mode
|
Forced Convection
|
Function
|
Temp. Range
|
RT+10-300℃
|
Temp. Resolution
Ratio
|
0.1℃
|
Temp. Motion
|
±1℃
|
Temp. Uniformity
|
±2.5%
|
Structure
|
Inner Chamber
|
SUS304
|
Outer Shell
|
Embossed SUS304
|
Insulation layer
|
High quality rock wool board(with CE)
|
Heater
|
Stainless steel heater
|
Power rating
|
0.8 kW
|
1.2 kW
|
1.6 kW
|
2.0 kW
|
2.3 kW
|
3.0 kW
|
Exhaust hole
|
φ 28 mm top (with function of test hole)
|
Rear Exhust
|
Controller
|
Temp. control mode
|
Two temperature section PID intelligent
|
Temp. setting mode
|
Touch button setting
|
Temp. display mode
|
Measuring temperature display on upper LCD screen, setting temperature display on the lower screen
|
Timer
|
0 - 9999 min (with timing wait function)
|
Operation function
|
Fixed temperature operation, timing function, auto stop.
|
Additional function
|
sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory
|
Sensor
|
PT100
|
Safety Device
|
High precision digital independent temperature limiter, over temperature sound and light alarm
|
Specification
|
Inner Chamber Size (W x L x H) (mm)
|
310 x 310 x
310
|
350 x 350 x
350
|
400 x 360 x
450
|
450 x 420 x 450
|
500 x 450 x 550
|
600 x 500 x 750
|
Exterior Size
(W x L x H) (mm)
|
450 x 500 x 690
|
490 x 540 x 730
|
540 x 550 x 830
|
590 x 610 x
830
|
640 x 640 x 930
|
730 x 680 x 1250
|
Packing Size
(W x L x H)
(mm)
|
550 x 585 x
845
|
590 x 625 x
885
|
640 x 635 x
985
|
690 x 695 x 985
|
740 x 725 x 1085
|
860 x 790 x 1400
|
Volume
|
30L
|
45L
|
65L
|
85L
|
125L
|
230L
|
Shelf number
|
6
|
7
|
9
|
8
|
13
|
17
|
Load per rack
|
15kg
|
Shelf space
|
35mm
|
Power Rating
(50 / 60 HZ)
|
AC 220 V/
3.6 A
|
AC 220 V /
5.5 A
|
AC 220 V/
7.2 A
|
AC 220 V /
9.0 A
|
AC 220 V /
10.5 A
|
AC 220 V/
13.6 A
|
NW/GW (kg）
|
33/37
|
37/43
|
44/49
|
50/56
|
60/66
|
Accessory
|
Shelf
|
2
|
Shelf frame
|
4
|
Optional Accessories
|
5.0-inch true color touch screen; USB data storage
|
Supplier Oven Lab - Forced Air Drying Oven di LTC Glodok
Drying Oven Product Catalog
|
FAITHFUL Drying Oven
|
BIOBASE Drying Oven
|
|
|
|
Forced Air Drying Oven - Used for drying, baking, wax, heat treatment Product Characteristic :
-
Horizontal air circularly by double Air ducts, high efficiency and high Uniformity.
-
PID controller, with over-temperature protection function.
-
With fan switch,LED digital display,high temperature blast motor.
-
New anti-hot handle
WGLL-BE series have the following characteristics other than the above functions Product Characteristic :
-
LCD temperature controller.
-
4 grades speed fan, adjustable for different requirements.
-
Over-temperature protection system.
-
High precision digital independent temperature limiter.
-
304:SUS304 Stainless Steel Body.
Model
|
WGL - 30B
|
WGL - 45B
|
WGL - 65B
|
WGLL - 30BE
|
WGLL - 45BE
|
WGLL - 65BE
|
WGLL - 30BE(304)
|
WGLL - 45BE(304)
|
WGLL - 65BE(304)
|
Cycle Mode
|
Forced convection
|
Function
|
Temp. Range
|
RT+10-300℃
|
Temp. Resolution Ratio
|
0.1℃
|
Temp. Motion
|
±1℃
|
Temp. Uniformity
|
±2.5%
|
Structure
|
Inner Chamber
|
Mirror Stainless Steel
|
Outer Shell
|
Cold rolling steel electrostatic spraying exterior
|
Insulation layer
|
High quality rock wool board(with CE)
|
Heater
|
Stainless steel heater
|
Power rating
|
0.8kW
|
1.2kW
|
1.6kW
|
Exhaust hole
|
φ 28 mm top (with function of test hole)
|
Controller
|
Temp. control mode
|
Two temperature section PID intelligent
|
Temp. setting mode
|
Touch button setting
|
Temp. display mode
|
B model : Measuring temperature: display on the four digital tubes upper row, setting temperature : display on the lower row
|
BE model : Measuring temperature display on upper LCD screen, setting temperature display on the lower row
|
Timer
|
0 - 9999 min (with timing wait function)
|
Operation function
|
Fixed temperature operation, timing function, auto stop.
|
Additional function
|
B model : Sensor deviation correction, temperature overshoot self- tuning, internal parameter locking, power-off parameter memory
|
BE model: High precision digital independent temperature limiter, 4 grade 3 speed adjustable-speed fan (230 and 625model BE without fan speed adjustor), sensor deviation correction, temperature overshoot self- tuning, internal parameter locking, power-off parameter memory
|
Sensor
|
pt100
|
Specification
|
Inner Chamber size
(W*L*H) (mm)
|
310 * 310 * 310
|
350 * 350 * 350
|
400 * 360 * 450
|
Exterior size
(W*L*H)(mm)
|
450 * 500 * 690
|
490 * 540 * 730
|
540 * 550 * 830
|
Packing size
(W*L*H) (mm)
|
550 * 585 * 845
|
590 * 625 * 885
|
640 * 635 * 985
|
Volume
|
30L
|
45L
|
65L
|
Shelf number
|
6
|
7
|
9
|
Load per rack
|
15 kg
|
Shelf space
|
35 mm
|
Power rating (50/60Hz)
|
AC220V/ 3.6A
|
AC220V/ 5.5A
|
AC220V/ 7.2A
|
NW/GW (kg）
|
33/37
|
37/43
|
44/49
|
Accessory
|
Shelf
|
2
|
Shelf frame
|
4
|
Optional Accessories
|
B model : Shelf ; BE model : Shelf, RS485 interface, printer, program temperature control device, remote control, wireless SMS alarm, USB data storage
|
Supplier Oven Lab - Forced Air Drying Oven di LTC Glodok
Drying Oven Product Catalog
|
FAITHFUL Drying Oven
|
BIOBASE Drying Oven
|
|
|
|
Model
|
WGL - 85B
|
WGL - 125B
|
WGL - 230B
|
WGL - 625B
|
WGLL - 85BE
|
WGLL - 125BE
|
WGLL - 230BE
|
WGLL - 625BE
|
WGLL - 85BE(304)
|
WGLL - 125BE(304)
|
|
|
Cycle Mode
|
Forced convection
|
Function
|
Temp. Range
|
RT+10-300℃
|
Temp. Resolution Ratio
|
0.1℃
|
Temp. Motion
|
±1℃
|
Temp. Uniformity
|
±2.5%
|
Structure
|
Inner Chamber
|
Mirror Stainless Steel
|
Outer Shell
|
Cold rolling steel electrostatic spraying exterior
|
Insulation layer
|
High quality rock wool board(with CE)
|
Heater
|
Stainless steel heater
|
Power rating
|
2.0kW
|
2.3kW
|
3.0kW
|
5.0kW
|
Exhaust hole
|
φ 28 mm top (with function of test hole)
|
Rear exhaust
|
Top double exhaust
|
Controller
|
Temp. control mode
|
Two temperature section PID intelligent
|
Temp. setting mode
|
Touch button setting
|
Temperature display mode
|
B model : Measuring temperature : display on the four digital tubes upper row, setting temperature: display on the lower row
|
BE model : Measuring temperature display on upper LCD screen, setting temperature display on the lower row
|
Timer
|
0 - 9999 min (with timing wait function)
|
Operation function
|
Fixed temperature operation, timing function, auto stop.
|
Additional function
|
B model : Sensor deviation correction, temperature overshoot self- tuning, internal parameter locking, power-off parameter memory
|
BE model: High precision digital independent temperature limiter,4 grade 3 speed adjustable-speed fan (230 and 625model BE without fan speed adjustor),sensor deviation correction, temperature overshoot self- tuning, internal parameter locking, power-off parameter memory
|
Sensor
|
pt100
|
Specification
|
Inner Chamber size (W*L*H)(mm)
|
450*420*450
|
500*450*550
|
600*500*750
|
660*760*1250
|
Exterior size (W*L*H)(mm)
|
590*610*830
|
640*640*930
|
730*680*1250
|
890*925*1830
|
Packing size (W*L*H)(mm)
|
690*695*985
|
740*725*1085
|
860*790*1400
|
1000*1080*2000
|
Volume
|
85L
|
125L
|
230L
|
625L
|
Shelf number
|
9
|
13
|
17
|
7
|
Load per rack
|
15 Kg
|
Shelf space
|
13 mm
|
Power rating (50/60Hz)
|
AC220V/ 9.0A
|
AC220V/ 10.5A
|
AC220V/ 13.6A
|
AC380V/ 13.2A
|
NW/GW (kg）
|
50/56
|
60/66
|
94/120
|
120/160
|
Accessory
|
Shelf
|
2
|
Shelf frame
|
4
|
Optional Accessories
|
B model : Shelf ; BE model : Shelf, RS485 interface, printer, program temperature control device, remote control, wireless SMS alarm,USB data storage
|
